Home / Custom 3.7V 1800mAh 803850 LiPo Battery with PCM & NTC for Portable Breast Pumps
The 103048 polymer battery is designed to carry air vaporizers and other portable equipment and offers reliable power in a compact and robust design. Its 1100mAh battery enables it to last longer, and the constant charging nature of the device enables it to have a consistent performance. Its small size makes it suitable to the modern electronic designs which need efficiency as well as space saving integration.
- Rated Capacity: 1100mAh
- Standard Voltage: 3.7V
- Charging Current: 1.0A
- Dimensions: 10*30*48mm
- Applicable Type: Carburetor
Get Free Quote
Download
Back to Product List
Overview
The Custom 3.7V 1800mAh 803850 LiPo Battery is designed for portable breast pumps, providing reliable rechargeable power in a compact, lightweight design. With a nominal voltage of 3.7V and a capacity of 1800mAh, this lithium polymer battery delivers 6.66Wh of energy for portable pumping devices. It features a built-in protection circuit module (PCM) and an NTC temperature sensor to support battery safety, temperature monitoring, and stable performance. GLOFLUX offers flexible OEM/ODM customization, including battery dimensions, capacities, wire lengths, connectors, and protection circuit configurations. Our engineering team works closely with equipment manufacturers to develop battery solutions tailored to specific device requirements. This battery is suitable for portable breast pumps, wearable pumping devices, and other compact rechargeable medical equipment applications.
Product Details
🔋 Battery Product Features
- Customization Supported: Can be customized to the customer's needs.
- High Power: Up to 20C discharge.
- Fast Charging: Up to 3C charging.
- Long Lifespan: Fits the criteria of long-term product use.
- Multi-Material System: Incorporates LCO, NCM, NCA, LFP, and other material systems.
- High Safety: Passes safety performance tests.
- Adequate Capacity: Adequate capacity to meet product design capacity.
- High Temperature Resistance: Operating temperature range -20℃ ~ 80℃.
🛡️ Lithium Battery Protection Board Features
- Charging Protection: Protection against overcharging.
- Discharging Protection: Stops excessive discharging.
- Overcurrent Protection: Prevents overcurrent.
- Short Circuit Protection: Prevents short circuit faults.
Application Scenarios
- Personal Care: toothbrushes, beauty appliances, electric.
- Sound: Headphones, speakers.
- Electronic Cigarettes: Electronic atomizers.
- Smart Devices: Fit trackers, toys, lights.
- Office Supplies: POS machines, portable printers.
- Financial Security: USB tokens.
- Medical Equipment: Medical devices.
Technical Parameters
| Model | 103048 |
| Rated Capacity | 1100mAh |
| Customization | Yes |
| Standard Voltage | 3.7V |
| Charging Current | 1.0A |
| Cell Size | 10*30*48mm |
| Finished Product Size | 10*30*50mm |
| Applicable Type | Air Vaporizer |
| Product Certifications | KC, CB, UN38.3, TUV, CQC, MSDS, CE, IEC62133 |
| Charging Time | 2h |
| Battery Type | Polymer Soft Pack |
| Rechargeable | Yes |
| Material | Lithium Cobalt Oxide |
| Charging Voltage | 4.2V |
| Storage Temperature | Room Temperature |
| Operating Temperature | Room Temperature |
| Net Weight | 30g |
| Shelf Life | 12 Months |
| Cell Standard | National Standard |
| Internal Resistance | 60 milliohms |
| Factory Voltage | 3.80V |
| Load Voltage | 4.2V |
